Specifications

Models

GH-5.6

MEASUREMENTS

US

A. Height – stowed

-lifting height

4 ft 6 in

18 ft 4.5 in

B. Length – platform

1 ft 7 in

C. Width – platform

-base (corner to corner)

2 ft

4 ft 5 in

PRODUCTIVITY

Load capacity

250 lbs

Storage/transport dimensions

14x14x39.5 in

POWER

Recommended PSI

85 psi

WEIGHT

Standard:

82 lbs

Features

Easily Configured to Meet Your Needs

PLATFORM OPTIONS

One-piece platform

Platform cradle package

POWER

Compressed air – CO2

BASE OPTIONS

GH 3.8

GH 5.6

Standard Features

MEASUREMENTS

GH-5.6

18 ft 4.5 lifting height

250 lb load capacity

PRODUCTIVITY

Portable and compact design

Up and down dump valve can be easily activated by patented control handle

The Super Hoist sets up in seconds – no tools required

The one-piece platform attaches to cylinder with a twist of the wrist

Legs fold up for easy storage

Easy-to-release leg lock keeps legs up for storage and out for use

Wheel brakes

Auto-lubricating oil reservoir on top of each piston inside the cylinder

Easy to service

POWER

Powered by CO2 or compressed air

One size fits all CO2 bottle mounting bracket
