Specifications

Models

GR-15

MEASUREMENTS

US

Working height

20 ft 8 in

Platform height

14 ft 8 in

A. Platform dimensions (L x W)

Standard

Standard with extension

Stock picker

Stock picker w/ adjustable tray

Standard AWP

Narrow AWP

35 x 29.5 in

55 x 29.5 in

35 x 28.75 in

56 x 28.75 in

27 x 26 in

26 x 20 in

B. Height – stowed

5 ft 2 in

C. Length – stowed

4 ft 5 in

D. Width

2 ft 5.5 in

E. Ground clearance – center

2.5 in

PRODUCTIVITY

Lift capacity

500 lbs

Lift capacity – extension deck

250 lbs

Drive speed – stowed

2.5 mph

Drive speed – raised

0.5 mph

Gradeability

30%

Turning radius – inside

-outside

Zero

4 ft 7 in

Raise / lower speed

21 / 19 sec

Controls

24V DC proportional

Tires – solid non-marking

10 x 3 x 8 in

POWER

Power source

24V (four 6V 225 Ah batteries)

Hydraulic system capacity

2.2 gal

WEIGHT

Weight:

2,192 lbs

STANDARDS COMPLIANCE

ANSI A92.6, CSA B354.2, CE Compliance, AS 1418.10

Features

Easily Configured to Meet Your Needs

PLATFORM OPTIONS

Standard platform with gate or sliding midrail

Extension platform with sliding midrail

Extension platform with gate

Stockpicker platform with dual side entry gates and adjustable tray

Standard AWP platform with sliding midrail

Standard AWP platform with gate

Narrow AWP platform with gate

POWER

24V (four 6V 225 Ah batteries)

TIRE

Non-marking solid tires

Standard Features

MEASUREMENTS

GR-15

20 ft 8 in (6.47 m) working height

14 ft 8 in (4.47 m) platform height

Up to 500 lb (227 kg) lift capacity

PRODUCTIVITY

Work station tray (GR-12, GR-15 only)

Standard platform with sliding midrail

Auxiliary platform lowering

Low 15.5 in (.39 m) platform entry height

Patented rigid mast system

Compact base 29.5 x 53 in (.75 x 1.35 m) (GR-12, GR-15 only)

Ground clearance 2.5 inches (stowed)

Fully proportional lift and drive controls

Battery charge indicator

Onboard diagnostic system

AC power to platform

Descent and tilt alarm

Zero inside turning radius

Dual wheel brakes

Hydraulic brake release

Pothole protection

Hinged rear ABS covers for easy access to all major electrical and hydraulic components

Tie down attachment points

Overhead crane attachment point

Large forklift pockets access

Non-marking solid tires

POWER

Automatic 25 amp battery charger
