When confronted with minimum floor space and only a hand pallet truck, the Thin Spin low-profile carousel is ideal for loading and unloading pallet applications. The Thin Spin is pallet truck loadable because of its sleek 7/8" overall height. The effective ramping length is
4-3/8"; slope is a mere 11°. A safety detent lock restricts carousel rotation when not in use.  Units require a starting force of 35 lbs. and a maintaining force of 25 lbs.

Usable Diameter: 45"

Overall Diameter: 54"

Height: 7/8"

Capacity: 4,000 lbs.
